Anti-Termite Reticulation System in Delhi

Quick answer

SKUAS installs anti-termite reticulation systems across Delhi from its head office on Okhla Road. We lay TermiPore porous pipe along every wall line before the plinth or floor PCC, charge it with Envu Premise SC at the IS 6313 dose, and refill it every 2 to 3 years without drilling.

TermiPore porous pipesEnvu Premise SC termiticideDosage as per IS 6313Written SKUAS warrantyServing since 20128,000+ clients

Delhi rebuilds itself plot by plot. Old kothis in South Delhi become four-storey builder floors, family homes in West and North Delhi are torn down and rebuilt, and new commercial blocks come up along the Ring Road and in Okhla and Mohan Cooperative. Every one of those sites sits on soil that has had termite colonies under it for decades.

That is why the foundation stage matters. Once the floor is cast, the only way to treat the soil under it is to drill through the tiles. A reticulation system laid before the plinth beam or floor PCC lets us re-treat the same soil every few years through junction boxes, with no drilling at all.

Termite risk in Delhi: what we plan for

Old colonies, established colonies of termites

Many Delhi plots are on land that has been built on and rebuilt since the 1960s. Old wooden door frames, buried construction waste and tree roots feed large subterranean termite colonies that are already in the soil when the new foundation goes in.

Monsoon moisture and dry summers

Termites move deeper in the dry heat of May and June and come up again after the monsoon, when the soil around foundations stays damp. A barrier that can be refilled keeps protection steady through these cycles instead of fading after the first few years.

Builder floors with shared foundations

A typical builder floor has one plinth shared by four or more owners. If termites get in, every flat is affected. Laying pipe once at the plinth stage protects all floors, and refills are done from outside without entering anyone's home.

Basements and parking stilts

Many Delhi plots now have a basement or stilt parking. We plan the pipe along the basement retaining walls and the stilt floor so that the lowest level, where termites enter first, is fully covered.

Reticulation pipe layout along boundary and internal walls with junction boxes, and a cross-section at the plinth
Typical layout we install in Delhi: porous pipe along every wall line, refilled through junction boxes outside.

Building already finished? Pipe cannot go under a finished floor. See termite control in Delhi for drill-fill-seal treatment of existing buildings.

Pipe and chemical we use in Delhi

TermiPore porous pipe cross-section showing micro-pores on all sides

The pipe we install

TermiPore porous pipe

Made in Vadodara, Gujarat, India from a thermoplastic elastomeric compound with a honeycomb micro-pore wall. Termiticide seeps out evenly through micro-pores on all sides, unlike hand-drilled PVC that leaks at a few holes. The manufacturer rates pipe life at 30 to 50 years (manufacturer estimate).

Sizes, specs and how to spot genuine pipe
Envu Premise SC termiticide 1 litre bottle

The chemical we charge it with

Envu Premise SC

Imidacloprid 30.5% SC from Envu (formerly Bayer Environmental Science). It is odourless and non-repellent: termites cannot detect it, carry it back to the nest and pass it on to the colony.

Why we use Premise SC

Reticulation plans in Delhi

PipeGuard Basic

Boundary protection for compact homes

  • Coverage: External boundary (plinth perimeter) only
  • Pipe: TermiPore 17.5 mm (green stripe)
  • Refill points: Junction box every 25 to 30 m
  • Chemical: First charge with Envu Premise SC
  • Warranty: Up to 3 years written SKUAS warranty
  • Refill: Refill recommended every 2 years
  • Flow test before covering
  • Installation photos

Rate: shared after a free site inspection

Get my estimate

PipeGuard Max

Builders, societies and commercial sites

  • Coverage: Boundary, internal walls and under-floor grid
  • Pipe: TermiPore 19.5 mm premium (red stripe)
  • Refill points: Brass-nipple junction boxes every 20 m
  • Chemical: First charge with Envu Premise SC
  • Warranty: Up to 10 years written SKUAS warranty with AMC
  • Refill: Scheduled refills under AMC
  • Pressure and flow test log
  • As-built drawing for handover
  • Annual inspection report

Rate: shared after a free site inspection

Get my estimate

Every site is different. Soil, plinth size, wall layout and access change the final figure, so we confirm the exact rate after a free site inspection. Warranty is SKUAS's own written service warranty; the period depends on the plan and site conditions.

Free estimate in 30 seconds

Reticulation System Estimator

Get the pipe length, number of refill points, chemical quantity and the right plan for your building. Our engineer then shares the exact rate on WhatsApp or call.

Buildings we protect in Delhi

Builder floors and kothis

Plinth-stage installation along the boundary and every internal wall line. One system protects all floors.

Independent houses being rebuilt

We coordinate with your contractor so the pipe goes in between excavation and the floor PCC.

Shops, offices and showrooms

Pipe along the boundary and column lines, with junction boxes placed where they do not affect the frontage.

Schools, clinics and institutions

Full grid under the floor with a pressure and flow log and an as-built drawing for the facility team.

How a Delhi installation runs

Our team works out of the SKUAS head office at 22 Ground Floor, Sarai Jullena, Okhla Road, so we can reach most Delhi sites the same day for a site visit. Pipe laying for a typical builder floor plinth takes one working day, and we schedule it around your contractor's backfilling or PCC date.

  1. Free site visit. We measure the plinth and mark wall lines on your drawing.
  2. Pipe laying. TermiPore pipe on a levelled bed along every planned line, joined to junction boxes.
  3. Flow test. Water is pumped through each loop before the pipe is covered.
  4. First charge. Premise SC at the IS 6313 dose of 5 L per m² of floor area.
  5. Handover. Photos, port layout and your refill reminder schedule.

Chemical quantity per charge

Chemical quantity per charge (IS 6313 dose of 5 L per m² of floor area)
Floor areaDiluted emulsionPremise SC concentrate
500 sq ft≈ 230 litres≈ 490 ml
1,000 sq ft≈ 465 litres≈ 980 ml
1,500 sq ft≈ 695 litres≈ 1.5 litres
2,000 sq ft≈ 930 litres≈ 2.0 litres
3,000 sq ft≈ 1,395 litres≈ 2.9 litres
5,000 sq ft≈ 2,325 litres≈ 4.9 litres
10,000 sq ft≈ 4,645 litres≈ 9.8 litres

Areas we cover in and around Delhi

South Delhi, Greater Kailash, Defence Colony, Lajpat Nagar, Saket, Malviya Nagar, Hauz Khas, Green Park, Vasant Kunj, Vasant Vihar, Chhatarpur, Okhla, Jamia Nagar, Kalkaji, CR Park, Alaknanda, Mayur Vihar, Preet Vihar, Rohini, Pitampura, Model Town, Punjabi Bagh, Rajouri Garden, Janakpuri, Dwarka, Uttam Nagar, Karol Bagh, Rajendra Nagar, Aerocity.

Frequently asked questions: reticulation in Delhi

Yes, as long as the floor PCC on the ground level has not been laid yet. We run the pipe along the plinth and every internal wall line and take plain pipe out to junction boxes on the outer wall or in the parking area.
We can lay pipe in a trench along the external walls and fit junction boxes for future refills. For the inside of the building, we combine it with drill-fill-seal treatment, because pipe cannot be placed under a finished floor.
Most Delhi sites can be visited within one to two working days from our Okhla Road office. Call or use the estimator and we will fix a time that matches your contractor's schedule.
It helps. With a plinth or floor plan we mark every wall line and junction box position before the site visit, which speeds up installation. If you do not have one, we measure on site.
TermiPore recommends a refill every 2 to 3 years. We send reminders and do the refill through the junction boxes in a few hours, without drilling or breaking tiles.

Aam sawal (Hinglish)

Ground floor ka PCC daalne se pehle. Ek hi system se saare floors protect ho jaate hain.
Okhla office se Delhi me zyadatar site par 1 se 2 din me visit ho jaata hai.
Haan, bahar ki diwaron ke saath trench me pipe lagta hai, aur andar drill-fill-seal treatment hota hai.

Building in Delhi? Book a free site inspection

Our engineer visits, measures the plinth and shares an itemised quote. The best time is before the plinth beam or floor PCC.
